64
HS-RC-C5E-AM-APC_01.fm
00/0211
c. Unscrew the Allen screw (F)
and remove it.
d. Unscrew the Allen screw (G)
until it idles. The screw is of
unsalable type and shall not be
removed.
e. Remove the module by slightly
moving away the lower part,
then lift it.
f. In case of resistance due to the
friction with the adjoining
modules:
– loosen all Allen screws of the
adjoining module.
– If that is not sufficient, keep on
loosening all screws of all
installed modules.
Illustrative picture with AMS-IAM module highlighted
Operating procedure (Continued)
To Next Page
