w. Saving the system
configuration:
w.1 Do not exit the Setup Menu
w.2 Press the softkey “Config” (key
F1)
w.3 Using the arrows, select item 1
“Save the configuration file
(Save)” and confirm by pressing
the Enter key
w.4 The “File” field automatically
highlights the configuration file
name and the related path
shown previously (e.g.
UD:\sys\cnfg\NJ1_01007.C5G
w.5 Confirm the saving using the
OK softkey (key F5). The
loading is confirmed by the
message “Activity in progress”
that is displayed for a short
while.
x. Restarting
the system:
x.1 Exit the Setup Menu (key L3)
x.2 In the Home screen, press the
softkey “Restart” (key F4)
x.3 Using the arrows, select item 1
“Complete (Cold)” and confirm
by pressing the Enter key
Follow-up procedure
– Do not stand under the Robot or in the areas nearby.
– Carry out some motion cycles at reduced speed to check the proper operating.
– Select the AUTO mode and check the proper operating at reduced speed.
