Combilift Ltd C2500-C3000CB O&S Manual
5-6
C2500CB-OM-EN-11
5.6 Fuse Box Layout
The diagram and table below show the layout of the fuse box & the rating for
each fuse.
5.7 Relay Layout
Below is a table of the relays inside the dash in the cabin of the Combilift.
PLC Loom Relay Table
Relay Function
1 Starter Solenoid
2 Glow Plug Timer
9 Steering Solenoid
15 Neutral Cut-Off
22 Work Lights (Spot Lights)
LV Valve Chest Lock Valve Solenoids
LPG (Toyota) LP Gas System Relay
C/O (Toyota) Engine Cut-Off Relay
PLC Loom Fuse Table
Fuse Amps Function
1-Diesel 7.5 Mast Height Override, Dash Display Lights, Glow Plug Light,
Glow Plug Relay, PLC Supply
1-GM LPG 7.5 Mast Height Override, Dash Display Lights, PLC Supply
1-Toyota LPG 7.5 Mast Height Override, Dash Display Lights, PLC Supply, LPG
Relay, Engine Plugs
2 7.5 Joystick Supply, Neutral Relay, Reverse Bleeper, PLC X3,
(Alternator Plug Pin 3 – Toyota Only)
3-Diesel 7.5 Pull Hold Solenoid, Fuel Pump
3-GM LPG 7.5 Ignition Coil, Fuel Commander
3-Toyota LPG 10 Engine Cut-Off, Distributor Plug J Pin 1
4 20 Steering Solenoid Supply, PLC Output Supply
5 7.5 Push Button Brake Switch, Inch Pedal Brake Switch, Brake
Light, Brake Solenoid Supply
6 7.5 Wiper
7 15 Front Work Lights, Dash Cluster Lights
8 15 Side Work Lights, Cabin Interior Light (Optional)
9 7.5 Cabin Heater Fan, Cabin Cooling Fan (Optional)
10 7.5 Horn
11 7.5 Independent Fork Positioning Solenoids
12 7.5 Proximity Switches Supply, Seat Switch, Seat Belt Switch
13 7.5 Flashing Beacon
14 7.5 Spare
Inline 10 Valve Chest Lock Valve Solenoids
