4.7: Hydraulic Oil & Filters
The hydraulic oil used in the Combilift should conform to the International
Standard. I.S.O. G344 HV grade oils with improved viscosity / temperature
characteristics. It should also have the correct temperature range for the
ambient temperature in which the machine is being operated. If the operating
temperature is outside the standard range, the standard oil should be
replaced with the correct grade.
Ensure that the correct type is used in the relevant ambient temperature. The
table below indicates a number of commercially available oils and the
temperature ranges that they are suitable for.
AMBIENT
OPERATING
TEMPERATURE
Low Range
-20°C to25°C
-4°F to 77°F
Standard Range
-10°C to35°C
14°F to 95°F
High Range
0°C to45°C
32°F to 113°F
Castrol: Hyspin AWH 32 AWH 46 AWH 68
B.P. Bartran HV 32 HV 46 HV 68
Esso: Univis N 32 N 46 N 68
Mobil 13 M 15 M 16 M
Shell: Tellus oil T32 T46 T68
Texaco HDZ 32 HDZ 46 HDZ 68
There are a total of 3 filters on or in the hydraulic oil tank that must be
replaced at certain intervals. These filters are:
1. The Suction Filter
2. The Return Filter
3. The In-Tank Strainer Filter
Note
The Sequence in which the brand names are listed does not signify any
grading as to their quality or preference.
Note
The machine is supplied with an AWH46 hydraulic fluid when leaving the
factory. Please check if this is suitable for the ambient temperature in which
the machine is to be operated
Note
Before adding hydraulic oil, ensure that all cylinders are retracted and fill to
upper level on the hydraulic oil level gauge.
Hydraulic Tank Capacity – 39 litres
Hydraulic System Capacity – 52 litres approx.
