Combilift Ltd C2500-C3000CB O&S Manual
1-1
C2500CB-OM-EN-11
Section 1: Machine layout and Operator Controls
1.1: Machine Overview and Components
It is essential before you start operating the Combilift to be familiar with the
main components and controls of the machine, their function and where they
are located. Figure 1 below and Figure 2 on the following page indicate the
major components of the machine and all of the operator controls.
Figure 1: Machine Component Layout – Front View
Component Layout
1. Forks
2. Front Swivels
3. Mast
4. Bonnet
5. Access Panels
6. Worklights
7. Strobe Beacon
8. Overhead Guard
9. Air Filter
10. LPG Tank / Diesel Tank
11. Rear Swivel
12. Exhaust
1
3
5
1
2
1
1
1
0
6
2
6
4
5
9
6
7
8
