INPUTS
Plug Pin Function WireColour
X4 01 RearWheel@ZeroDegreeProximitySwitch Black
X4 02 FrontWheel@ZeroDegreeProximitySwitch Black
X4 03 RearWheel@NinetyDegreeProximitySwitch Black
X4 04 FrontWheel@NinetyDegreeProximitySwitch Black
X4 05 CarouselStee ringProximitySwitch(DBProxy) Black
X4 06 ParkBrakeSwitchSignal Orange
X4 07 InchingPedalBrakeSwitchSignal(Optional) Orange
X4 08 ForwardSignalFronDirectionLever White
X4 09 PowerSupplytoBoard(SuppliedFromFuse1) Red
X4 10 NegativeforBoardpowerSupply Blue/Black
X4 11 ReverseSign al FromDirectionLever Brown
X4 12 LeftSignalFromDirectionLever Grey
X4 13 RightSignalFromDirectionLever Green
X4 14 MastHeightProximitySwitchSignal Yellow
X4 15 MastHeightOverRideButton Red
X4 16 Optional Extra n/a
X4 17 Optional Extra n/a
X4 18 SeatSwitchSignal Grey
OUTPUTS
Plug Pin Function WireColour
X3 01 ForwardSolenoid01  White
X3 02 ForwardSolenoid02  White
X3 03 ReverseSolenoid01  Brown
X3 04 ReverseSolenoid02  Brown
X3 05 CommonSupplyforPins01‐04(FromFuse2) Red
X3 06 DriveSolenoid01 Red
X3 07 DriveSolenoid02 Red
X3 08 NinetydegreeIndicatorLight Green
X3 09 ZeroDegreeIndicatorLight White
X3 10 CommonSupplytopins06 ‐09(FromFuse4) Brown
