Note
Turn the ignition key switch to the ‘0’ off position and isolate the battery
before working on the truck’s electrical system.
7.5 Fuses
7.5.1 14-Way Fuse Box
The 14-way (ATO/regular blade fuse) fuse box is
located on the dash to the right of the armrest (see
item 23 in figure 3.2 on page 28). Remove the
cover from the fuse box to access the fuses.
The fuses are arranged in the order shown in the
table to the right.
The fuses are numbered from 1 to 14 on the fuse
box. The table below gives the rating of each fuse
and the function related to each fuse in the 14-way
fuse box.
14-Way ATO/Regular Blade Fuse Table
Fuse Amps Circuit
1 7.5
Mast Raised Drive Cut-Out Override, Low LPG Warning Buzzer,
Displa
y
Console & Pro
g
rammin
g
Port, En
g
ine ECU Enable
2 7.5
Four-Way Direction Switch, Neutral Relay Pin 86, Starter Relay Pin 86,
LPG En
g
ine MIL
(
malfunction indicator li
g
ht
)
3 7.5 6-Way Auxiliary Fuse Box Relay
4 20 Steering 6-Port Diverter Valve Solenoid Supply
5 7.5
Push Button Brake Switch, Inch Brake Pedal Brake Switch, Brake
Li
g
hts
(
If Fitted
)
6 15 Wiper Motor(s)
7 7.5 Work Lights Relay
8 15 Cabin Auxiliary Hydraulic Function Solenoids
9 10
Cabin Heater Fan, Cabin Heating Valve Switch, Cabin Cooling Fan,
Optional Radio
10 7.5 Horn
11 7.5 Proximity Switch Supply
12 7.5
Seat Switch, Seat Belt Switch (If Fitted), Joystick/Lever Buttons (If
Fitted
)
, Air Seat Rela
y
Pin 86
(
If Fitted
)
13 7.5 Flashing Beacon
14 10
12v Dash Plug Supply (If Fitted), Extra Oil Cooler Relay Pin 86 (If
Fitted
)
, Air Conditionin
g
Rela
y
Pin 86
(
If Fitted
)
Fuse 5 Fuse 10
Fuse 14
Fuse 4 Fuse 9
Fuse 13
Fuse 3 Fuse 8
Fuse 12
Fuse 2 Fuse 7
Fuse 11
Fuse 1 Fuse 6
