Operation Monitoring
48
C3M2-OM-EN-02
14. Right Hand Turn Indicator Lights Icon **
The right-hand turn indicator lights icon can only light up on trucks
that have optional road lights fitted.
The icon flashes green when the right turn indicator lights are
activated.
** Only applies if road lights have been fitted.
15. Neutral Icon
The neutral icon lights up green when the four-way direction switch
is in the neutral position.
16. Forward Drive Direction Icon
The forward drive direction icon lights up green when forward drive
is selected with the four-way direction switch and the park brake is
released.
17. Reverse Drive Direction Icon
The reverse drive direction icon lights up green when reverse drive
is selected with the four-way direction switch and the park brake is
released.
18. Left Drive Direction Icon
The left drive direction icon lights up green when left drive is
selected with the four-way direction switch and the park brake is
released.
19. Right Drive Icon
The right drive direction icon lights up green when right drive is
selected with the four-way direction switch and the park brake is
released.
20. Seat Interlock Icon
The seat interlock icon is displayed when the operator is not sitting
in the seat.
The drive is disabled and the hydraulic mast and fork functions are
disabled when this icon is displayed.
The park brake is automatically applied when the operator is not
sitting in the seat.
21. Seat Belt Interlock Icon ****
The drive is disabled when this icon is displayed.
The icon is displayed when the operator is sitting in the seat but
does not have the seat belt buckled.
It appears in the same position on the screen as the seat interlock
icon.
**** Only applies if a seatbelt switch has been fitted.
