Comelit 3360B - Changing the RS485 Address of the Porter Module; Viewing the Number of Names Entered in the Directory, the Software Version, the Number of Passwords Entered and the ID Code; Rs485 Address

19 19
PARAMETER
CHANGED
15. Changing the RS485 address of the porter
module
1. access programming mode, see page 6
2. select the menu items:
Settings ⇒ System parameters ⇒ RS485 address
RS485 ADDRESS
002
SCROLL OK
ESC ESC
PARAMETER
CHANGED
SPEAKER PARAMETERS
RS485 ADDRESS
OK OK
SCROLL ESC
3. enter the RS485 address (max. 3 digits) using the
alphanumeric keypad
4. press or to conrm
16. Viewing the number of names entered in
the directory, the software version, the number
of passwords entered and the ID code (RS485
address)
1. access programming mode, see page 6
2. select the menu item:
Info
REV. 1.0
RS485 ADDRESS
001
SCROLL ESC
REV. 1.0
PASSWORDS ENTERED
0010
SCROLL ESC
REV. 1.0
NAMES STORED
0020
SCROLL ESC
NAME DIRECTORY
ACCESS CONTROL
SETTINGS
INFO
OK OK
SCROLL ESC
3. press or to conrm
4. to display the information, scroll through the directory
using
4. select YES to enable the function, NO to disable it
5. press or to conrm
» * indicates active selection
