Operation Instructions
5-17
Interval:
P Time Limit (Average Value of the Average Cardiac Beat P Wave Time Limits of Many Leads)
PR Interval (Average Value of the Average Cardiac Beat PR Intervals of Many Leads);
QRS Time Limit (Average Value of the Average Cardiac Beat QRS Wave Time Limits of Many
Leads);
QT/QTC Interval (Average Value of the Average Cardiac Beat QT Intervals of Many
Leads/Normalized QT Intervals);
Axis:
P/QRS/T Electric Axis (ECG Axis is the Main Direction of the Average Synthetic Vector on the
Frontal Plane);
Amplitude:
RV5/SV1 Amplitude (Maximum Amplitude in the Average Cardiac Beat R and R‟ Waves of the
Lead V5/Maximum Amplitude Absolute Value in the Average Cardiac Beat S and S‟ Waves of Lead
V1);
RV5+SV1Amplitude (Sum of RV5 and SV1);
RV6/SV2 Amplitude (Maximum Amplitude in the Average Cardiac Beat R and R‟ Waves of the
Lead V6/Maximum Amplitude Absolute Value in the Average Cardiac Beat S and S‟ Waves of Lead
V2);
Minnesota Code: The code of various diagnosis and diagnostic basis
Diagnosis Information: The diagnosis information shows the results of the automatic diagnosis.
Confirmed by: the doctor sign here after confirming the ECG waveform;
This equipment is detecting equipment instead of diagnosis equipment, and it is only responsible
for those indicators regulated by relevant national standards. The diagnosis information selected
and printed by doctors is the adjunctive and optional software function of this equipment, and
can only be the reference for diagnosis use. The doctor should sign after diagnosis and
confirmation according to actual ECG waveform. The doctor should be responsible for printed
reports
5.5 Rhythm Mode
Under the rhythm mode, the user can select any rhythm lead according to the need from І, II, III, aVR,
aVL, aVF, V1, V2, V3, V4, V5 and V6 and record the rhythm waveform of the lead.
