Operation Instructions
5-20
5.7 Printing
1) Automatic: Press the MODE key to select “Automatic” mode, and press the START/PRINT key to print
automatically.
In the automatic printing, the channel is set as 3×4 and the 12 leads record in the mode of 3
channels and 4 sequences, record each sequence for 2.5s.
In the automatic printing, the channel is set as 6×2 and the 12 leads record in the mode of 6
channels and 2 sequences, record each sequence for 5s.
In the automatic printing, the channel is set as 12×1 and the 12 leads are recorded in 12 channels in
order and record each sequence for 10s at the same time.
In the automatic printing, the channel is set as 3×4+1R and the 12 leads are recorded in 3 channels
and 4 sequences ，record 2.5 seconds for each sequence and add 1 channel of rhythm lead
waveform.
Before printing, relevant parameters should be set, such as: average template, save option,
rhythm lead and so on. For detailed information, please refer to relevant chapters.
2) Manual: Press the MODE key to select “Manual” mode and then press the START/PRINT key to print
manually.
In the manual printing, the Channel Model is set as 3×4 and the 12 leads are recorded in 3 channels
and 4 sequence. Press the right and left key of arrow keys group to switch leads. The leads
switching order is I，II, III; AVR, AVF, AVL; V1, V2, V3; V4, V5, V6.
In the manual printing, the Channel Model is set as 6×2 and the 12 leads are recorded in 6 channels
and 2 sequence. Press the right and left key of arrow keys group to switch leads. The leads
switching order is I, II, III, AVR, AVF, AVL; V1, V2, V3, V4, V5, V6.
When the channel format of automatic mode is set as 12×1, the 12 leads will be recorded in 12
channels in sequence order, and the leads can not be switched.
5.8 ON State of the Average Template
Take the automatic print of the ECG record of the 6×2 channel mode and 3×4+1R average template as an
example for the ON State of average template, it is composed of part (a) and part (b):
