Operation Instructions
5-19
Note
 The ECG waveform and data will not be saved under manual mode.
Figure 5-16 Manual Print Channel Mode 6×2
Above is the ECG record of channel mode 6×2 under the manual mode, the content includes:
 ID: (Patient ID)
 Name: (Patient‟s Name)
 Sex: Male (Patient‟s Sex)
 Data Time: (Current Date, Current Time)
 Age: 0 (Patient‟s Age)
 Blood Pressure:0 mmHg ( Patient‟s Diastolic Pressure as High Pressure)
 Hospital: (Hospital Name)
 Height:0 cm (Patient‟s Height)
 Weight: 0 kg(Patient‟s Weight)
 Hospital NO.
 (1mV Calibration Signal)
 І, II, Ш, aVR, aVL, aVF (6 Standard Lead Mark Symbol) and ECG waveform
 Manual Print 6L
 Heart Rate: 60 bpm (Patient‟s Heart Rate Value)
 10mm/mV (Gain)
 0.05~25Hz (0.05Hz Baseline Drift Filter, 25Hz Lowpass Filter)
 50Hz (AC Filter)
 25mm/sec (Record Speed)
 Confirmed by: doctor sign here after confirming the ECG waveform;
