Comen H3 - Positions of Limb Electrodes

Operation Preparation
3-6
Chest 6
C6
White/violet
V6
Brown/violet
3.4.1 Positions of Limb Electrodes
1) Limb Electrode (Clamp type):
Figure 3-3Limb electrode
2) Connect limb electrode:
R electrode — Right limb connected as figure 3-4
L electrode — Left limb
N electrode —Right leg
F electrode —Left leg
C1～C6 chest electrode connected as figure 3-6
Figure 3-4Positions of four limb electrodes
Reed
Electrode
Clamp
