2) Direct drain
This is an alternative configuration to manually draining the waste water recovery tank 11
(see MANUALLY DRAIN TANKS).
Connect the tube fitted with a male quick connector to the female fitting on the direct
drain 30 after placing the other end of the tube at a suitable drain.
Once the pipe is connected, any water in the waste water recovery tank 11 will start to
drain.
Water supply table
Water supply
Residue from evaporation ≤10 mg/l
Silicon Dioxide SiO
2
≤1 mg/l
Iron ≤0.2 mg/l
Cadmium ≤0.005 mg/l
Lead ≤0.05 mg/l
Remaining heavy metals excluding iron,
cadmium, lead
≤0.1 mg/l
Chlorides ≤2 mg/l
Phosphates ≤0.5 mg/l
Conductivity (at 20°C) ≤15 µS/cm
Acidity value pH From 5 to 7
Appearance Colorless, clean, without sediment
Hardness ≤0.02 mmol/l
WARNING: liquid temperature can reach 80°C, and the liquid may be
contaminated. The liquid should be disposed of according to the legislation in
force.
!
Installation
