56
INDICATORS
Indicators are messages containing notices or warnings that in most cases require a simple
corrective action or check from the user.
The indicators are shown on the display with the corresponding icon and a brief
description.
Description /
• Solution
Indicates that a scheduled maintenance procedure is
needed for one or more components.
• contact a technical service center.
Indicates that a start has been programmed for the cycle
on the display. The cycle will begin automatically at the
date and time displayed.
Maximum level reached in Clean water tank 10.
Minimum level reached in Clean water tank 10.
• Fill the tank.
Activates when the auto water fill 29 is set.
Indicates that the conductivity value of the water
introduced has exceed the optimum level but is still
acceptable; the sterilizer allows a cycle to begin, but it is
advisable to proceed according to instructions given for
the WATER QUALITY INSUFFICIENT ALARM (see ALARMS).
Indicates that the waste water recovery tank 11 is full.
• Empty the tank (see MANUALLY DRAIN TANKS).
If the direct drain 30 is installed (see CONNECTIONS),
check the correct connection and that the pipe is not
bent or clogged.
Indicates that the temperature in the chamber 09 is not
suitable to start or continue a cycle.
Sterilizer preheating; the indicator notifies you that the
external coil is operating.
During the cycle, this indicates that the device that locks
the door 16 is active; it means that the door is closed and
locked.
Indicates that the cycle has completed and that the
sterilizer is ready to begin a new cycle.
Indicators
DRAIN WASTE
WATER
MAX WATER
LEVEL
MIN WATER
LEVEL
PREHEATING
DOOR
LOCKED
CYCLE
COMPLETED
CHECK WATER
QUALITY
COOLING
PAUSE
MAINTENANCE
SCHEDULE
PROGRAMMED
START
