Comm-Tec MTX88UH2 - Page 24

4K 8x8 HDBaseT Matrix Switcher
Comm-Tec S.r.l. 23 www.comm-tec.it
Command
Function
Feedback Example
EDIDG[x].
Get EDID data from output [x] and display
the output port number.
Hexadecimal EDID
data and carriage
return character
EDIDMInit.
Restore the factory default EDID data of
every input.
EDIDMInit.
EDIDM[X]B[Y].
Manually EDID switching. Enable input[Y]
to learn the EDID data of output[X]. If the
EDID data is not available, then set it as
initialized EDID data.
EDIDM[X]B[Y]
EDIDUpgrade
[x].
Upgrade EDID data via the RS232 port.
[x] is the input port, when the value of X is
9, it means to upgrade all input ports.
When the switcher receives the
command, it will show a message to
prompt you to send EDID file (.bin file).
Operations will be canceled after 10
seconds. Please cut off all connections of
HDBaseT ports.
Please send the EDID
file
EDID/[x]/[y].
Set the EDID data of input port [x] to built-
in EDID No.[y].
[y]=1~6, correspond to the 6 embedded
EDID data
EDID/[x]/[y]
UpgradeIntED
ID[x].
Upgrade one of the 6 embedded EDID data,
x is the serial number for EDID data
1. 1080P 3D 2CH
2. 1080P 3D Multichannel
3. 1080P 2D 2CH
4. 1080P 2D Multichannel
5. 3840x2160 2D (30Hz)
6. 4096x2160 2D (30Hz)
When the switcher gets the command, it
will show a message to send EDID file
(.bin file). Operations will be invalid after
10 seconds.
Please send the EDID
file
GetIntEDID[x].
Return the embedded EDID data ranked
x, [x]=1~6
GetInPortEDI
D[X].
Return the EDID data of input [x], [x]=1~8
%0801.
Auto HDCP management, activate carrier
native mode
%0801
