4K 8x8 HDBaseT Matrix Switcher
Comm-Tec S.r.l. 32 www.comm-tec.it
settings
Configuration: Set HDCP Cmpliance status for every input, and manage EDID. See
the screenshot below:
Network: Inquire and configure network settings including MAC address, IP address,
subnet mask, and Gateway
Note: Log in as user access main interface only.
4.4.4 Port Management
Type the designed website 192.168.0.178:100 (Default, changeable via GUI) in your
browser. Enter correct username and password (same with GUI name and password)
to log in the WebServer:
Here is the main configuration interface of the WebServer:
