Comm-Tec MTX88UH2 - System Connection

4K 8x8 HDBaseT Matrix Switcher
Comm-Tec S.r.l. 8 www.comm-tec.it
④
IR ALL IN
Input port for IR control signal, connect with IR receiver (with
carrier), delivers the received IR signal to all the 8 far-end
receivers.
⑤
TCP/IP
TCP/IP port for unit control
⑥
IR EYE
Connect with extended IR receiver, use the IR remote to
control the 4K HDBaseT 8x8 Matrix Switcher.
⑦
Power
Trigger
Press the button to turn on/off the matrix. The indicator turns
red when power on.
⑧
Power port
Connect to an AC 100V~240V power adapter via the included
power cord
⑨
GROUND
Connect to grounding, make the unit ground well.
Note: Pictures shown in this manual are for reference only, different model and
specifications are subject to real product.
3. System Connection
3.1 System Applications
As its good performance in control and transmission, the 4K HDBaseT 8x8 Matrix
Switcher can be widely used in computer realm, monitoring, large screen displaying,
conference system, television education and bank securities institutions etc.
3.2 Usage Precautions
1) System should be installed in a clean environment and has a prop temperature and
humidity.
2) All of the power switches, plugs, sockets and power cords should be insulated and
safe.
3) All devices should be connected before power on.
3.3 Connection Diagram
