Comm-Tec MTX88UH2 - Specification

4K 8x8 HDBaseT Matrix Switcher
Comm-Tec S.r.l. 35 www.comm-tec.it
5. Specification
Video Input
Video Output
Input
8 HDMI
Output
4 HDMI
8 HDBaseT
Input
Connector
Female HDMI
Output
Connector
Female HDMI
Female RJ45(with LED
indicators)
Input Level
T.M.D.S. 2.9V~3.3V
Output Level
T.M.D.S. 2.9V~3.3V
Input
Impedance
100Ω (Differential)
Output
Impedance
100Ω (Differential)
HDBaseT
Output
Up to
70m1080P@60Hz/
40m4Kx2K@30Hz
Video General
Gain
0 dB
Bandwidth
10.2 Gbit/s
Video Signal
HDMI (or DVI-D)
Maximum
Pixel Clock
225MHz
Resolution
Range
Up to 4Kx2K, 1080P 3D
Switching
Speed
200ns (Max.)
Max Pixel
Clock
225MHz
EDID
Management
In-built EDID data
and manual EDID
management
Audio General
Output Signal
Analog audio
Output
Connector
3-pin pluggable
terminal block
PCM Format
Distortion: 0.1%
32Ω/70mW@1KHz,
0.1% 16Ω/105mW
@1KHz
Frequency
Response
20Hz~20KHz
CMRR
>90dB @20Hz ~ 20KHz
Control Parts
Control Ports
8 IR OUT (green and
red)
8 IR IN (black)
1 IR EYE (black)
1 IR ALL IN (black)
1 TCP/IP (female RJ45)
1 RS232 (9 pin female)
Panel Control
Front panel buttons
