Comm-Tec UP-41TS - Product Introduction; Features; Package List

Compact Scaler Switcher
Comm-Tec S.r.l. 4 www.comm-tec.it
1. Product Introduction
Thank you for selecting the 6x1 4k presentation switcher. The presentation switcher offers
four HDMI, one display port and one USB-C inputs along with mirrored HDMI and HDBaseT
outputs. The HDBaseT output supports PoC and can be paired with a compatible HDBaseT
receiver to extend 4k@30Hz/1080P signal up to 40 meters (131ft) / 70 meters (230ft) all over
a single CATx cable.
The switcher features external line audio input that can be embedded into any HDMI input,
and provides microphone input for audio mixing. The presentation switcher provides multi-
view functionality and supports up to 16 multi-mode layouts. The switcher features a wide
range of control flexibility via front panel buttons, built-in web GUI, IR remote, RS232 and
CEC.
1.1. Features
⚫ 6x1 4K Presentation Switcher with HDBaseT output.
⚫ Supports seamless and auto switching.
⚫ HDMI 1.4 and HDCP 2.2 compliant.
⚫ Extends HDMI signals to distance up to 40 meters at 4K and 70 meters at 1080p.
⚫ Supports audio embedded, audio de-embedding and microphone audio mixing.
⚫ Supports multi-view and up to 16 modes can be selected.
⚫ Controllable via front panel buttons, GUI, IR remote, RS232 and CEC.
1.2. Package List
⚫ 1x 6x1 4K Presentation Switcher
⚫ 2x Mounting Ears with 4 Screws
⚫ 4x Plastic Cushions
⚫ 2x 3-pin Terminal Blocks
⚫ 2x 5-pin Terminal Blocks
⚫ 1x IR Remote
⚫ 1x IR Receiver
⚫ 1x IR Emitter
⚫ 1x RS232 Cable (3-pin to DB9)
⚫ 1x Power Adapter (24V DC 5A)
⚫ 1x Power Cord
⚫ 1x User Manual
Manufacture
This product is manufactured by:
SHENZHEN PTN Electronics Limited
Add: B6, JinXiongDa Technology Park, HuanGuan Road South 105th
GuanLan Block, LongHua New District
ShenZhen City, 518110, China
Tel: +86-755-2846 1819 - Fax: +86-755-8471 7796
Service: Support@PTN-electronics.com
Sales:Info@PTN-electronics.com
Website:www.ptn-electronics.com
