Comm-Tec UP-41TS - Special Commands

Compact Scaler Switcher
Comm-Tec S.r.l. 34 www.comm-tec.it
7.6. Special Commands
Note: The below commands don’t need ending mark.
Command
Description
Command Example and
Feedback
>SetDisplayInputSendC
har_[Param]:XXXX
Set the ASCII “Display Input Select”
command "XXXX" to be sent to display
device when power on the switcher.
[Param] = 1~5 (Baud rate of RS232 port)
1 - 115200
2 - 57600
3 - 38400
4 - 19200
5 - 9600
XXXX= ASCII data to be sent (Up to 48
characters).
>SetDisplayInputSendChar
_5:1234567
<Baudrate: 9600
<Display input select to
send:1234567
>SetDisplayInputSendH
ex_[Param]:XX XX
Set the HEX “Display Input Select” command
"XX XX" to be sent to display device when
power on the switcher.
[Param] = 1~5 (Baud rate of RS232 port)
1 - 115200
2 - 57600
3 - 38400
4 - 19200
5 - 9600
XX XX= HEX data to be sent (X = 0~9, A~F
and up to 20 XX).
>SetDisplayInputSendHex_
5:30 31 32 33
<Baudrate: 9600
<Display input select to
send HEX:30 31 32 33
>SetPowerOnSendChar
_[Param]:XXXX
Set the ASCII “Power On” command "XXXX"
to be sent to display device when power on
the switcher.
[Param] = 1~5 (Baud rate of RS232 port)
1 - 115200
2 - 57600
3 - 38400
4 - 19200
5 - 9600
XXXX= ASCII data to be sent (Up to 48
characters).
>SetPowerOnSendChar_5:
1234567
<Baudrate: 9600
<Power on to
send:1234567
>SetPowerOnSendHex
_[Param]:XX XX
Set the HEX “Power On” command "XX XX"
to be sent to display device when power on
the switcher.
[Param] = 1~5 (Baud rate of RS232 port)
1 - 115200
>SetPowerOnSendHex_5:3
0 31 32 33
