Comm-Tec UP-41TS - Page 6

Compact Scaler Switcher
Comm-Tec S.r.l. 6 www.comm-tec.it
Noise Level
-80dB
SPDIF Audio Output
SPDIF Out
(1) SPDIF
Audio Out Connector
(1) Toslink
Max Output level
±0.3dBFS
Frequency Response
20Hz ~ 20kHz, ±1dB
THD+N
< 0.05%, 20Hz ~ 20kHz bandwidth, 1kHz sine at 0dBFS level (or max
level)
Signal-to-Noise Ratio
> 90dB, 20Hz ~ 20kHz bandwidth
Crosstalk isolation
< -70dB, 10kHz sine at 0dBFS level (or max level before clipping)
Noise
- 90dB
Audio Format
PCM 2.0
Control
Control port
(1) CONTACT IN, (1) IR IN, (1) IR OUT, (1) IR EYE,
(1) FIRMWARE, (1) RS232, (1) TCP/IP
Control Connector
(1) 5-pin terminal block, (3) 3.5mm jack, (1) Type-A USB,
(1) 3-pin terminal block, (1) RJ45
General
Operation Temperature
-5℃ ~ +55℃
Storage Temperature
-25℃ ~ +70℃
Relative Humidity
10% ~ 90%
External Power Supply
Input: AC 100~240V, 50/60Hz; Output: 24V DC 5A
Power Consumption
90w (Max)
USB-C Power Charging
60w (Max)
Dimension (W*H*D)
250mm x 44mm x 200mm
Net Weight
1.6KG
