 Pin out of PoE Endspan Hub/Switch
Pin
Signal / Name
1
TX+/VCC+
2
TX-/VCC+
3
TX+/VCC-
4
5
6
TX-/VCC-
7
8
Note
‘+’ and ‘-‘ signs represent the polarity of the wires that make up each wire pair.
Before you power PD, please check the RJ45 connector pin assignment follow
IEEE802.3af standard; otherwise you may need to change one of the RJ45
connector pin assignment attached with the UTP cable.
