JHT01 Service Manual
5-20
1.12 Removing the LCD Module
To remove the LCD module, first remove the keyboard. Then follow the steps
below:
1. Disconnect the LCD power (LVDS), CMOS, and microphone cables and pull
the wireless and TV tuner card antennas free from the laptop as shown.
2. Remove one screw securing the CMOS cable and the four screws securing the
LCD module to the logic upper.
To Next Page
