Compal JHT01 - IOMP Button; Adapter Loading Control; External Leds Status Report and Control

JHT01 Service Manual
2-27
12.5.9 Power USB Button
In S3 mode AC + BATTERY AC only BATTERY only
JHT0x_JHL9x Support Support Support
• Power USB Button also be supported in S3 and S5 mode
12.6 IOMP button
12.6.1 Mode Button
• Open the Media player under Windows mode.
12.6.2 Next One Button
•
Press/Release short than 2 sec: Next One
• Press/Release more than 2 sec: Volume Up
12.6.3 Play / Pause Button
• Press/Release short than 2 sec: Play / Pause
•
Press/Release more than 2 sec: Stop
12.6.4 Last One Button
• Press/Release short than 2 sec: Last One
• Press/Release more than 2 sec: Volume Down
12.7 Adapter loading control
•
If power that system need is more than adapter loading, EC will determine
this adapter is wrong power adapter and notifies as below:
• With battery, system will stop charge if battery is not full.
• Without battery, system will shutdown if system power on.
• Note: When EC determine the adapter is wrong power adapter, until adapter
plug-out or system off (Reset one time).
12.8 External LEDs status report and control
12.8.1 Definitions of Lock LEDs
•
Caps lock LED (Blue): Caps Lock State of Keyboard
• Scroll Lock LED (80 Model: White or 80i/81/81i Model: Green): Scroll Lock
State of Keyboard (No Support)
• Number Lock LED (Blue): Number Lock State of Keyboard
•
NOTE: In normal mode (Cursor and Num function are disable), when users
press Hot Key, the Cursor LED will be on. When users re-press Hot Key, the
Cursor LED will be off.
