3.11 BATTERY
3.11.1 Li-Ion smart
3.11.2 Battery Specification
1-1. EE information
6 cell 6 cell 9 cell
Battery Design Capacity
(mAH)
4800 5200 7200
Battery Configuration 3S2P 3S2P 3S3P
Battery Nominal Voltage
(V)
11.1 11.1 11.1
Single Cell Chemistry Li-ion Li-ion Li-ion
Single Cell Type 18650 18650 18650
Single Cell Capacity
(mAH)
2400 2600 2400
Dumb/Smart Battery
Smart Battery
(SMBus ver. 1.1.)
Smart Battery
(SMBus ver. 1.1.)
Smart Battery
(SMBus ver. 1.1.)
Cycle Life 70% after 300 cycles 70% after 300 cycles 70% after 300 cycles
Nominal Charging
Voltage (V)
12.6 12.6 12.6
Nominal Charging Current
(A)
3 3 3
Protection Function
OVP
UVP
OTP
OCP
OVP
UVP
OTP
OCP
OVP
UVP
OTP
OCP
1-2. Battery Connector Pin Assignment
Connector Male on M/B: TBD
Connector Female on Battery: SUYIN-200274FS009GX01ZU
Pin No. Symbol Comments
1 BATT+ Batt+, Battery Positive Terminal.
2 BATT+ Batt+, Battery Positive Terminal.
3
ID Identify pin (Note 1)
4 B/I Battery-In Pin (Note 2)
