Compal JHT01 - System Component Summary

JHT01 Service Manual
2-1
1. System Components Summary
Processor
–
Intel Penryn 45nm Standard Voltage:
 2.8GHz, 1066MHz FSB, 6MB L2 cache
 2.53GHz. 1066MHz FSB, 6MB L2 cache
 2.26GHz, 1066MHz FSB, 3MB L2 cache
 2.40GHz. 1066MHz FSB, 3MB L2 cache.
FSB
–
667/800/1066 MHz FSB support
Core Logic
– Intel Montevina platform:
–
JHL90/JHT00: Cantiga PM + ICH9M.
– HL91/JHT01: Cantiga GM + ICH9M.
System Memory
–
No on board memory
– Support DDR-II 667/800MHz
–
Two SODIMM with 1GB/2GB modules
–
Easy upgrade from bottom side for two SODIMM.
– Max. 4GB
Display
– 15.4” (16:10) WXGA (1280x800) (glare/anti-glare and anti-
reflection)
–
15.4” (16:10) WXGA+ (1440x900) (glare/anti-glare and
anti-reflection)
– 15.4” (16:10) WSXGA+ (1680x1050) (glare/anti-glare and
anti-reflection)
– 14.1” (16:10) WXGA (1280x800) (glare/anti-glare and anti-
reflection)
HDD
– 9.5mm, 2.5” S-ATA HDD
–
support with 80/120/160/250GB (5400rpm) capacity
– support with 120/160GB (7200rpm) capacity
– Easily removable no more than two screws
Optical Drives
– Fixed 12.7mm height SATA ODD:
–
Combo (CD-RW/DVD-ROM/DVD Dual) (8x)
 DVD-RAM/-R/-RW readable
– DVD Super-Multi (DVD-RAM/-R/-RW/+R/+RW Super
Multi)
 DVD-RAM/-R/-RW writable
 Support Double-Layer Recording is required
High Definition Disc (BD-Multi ROM)
– Blue-Ray Writable
– Blue-Ray ROM
