JHT01 Service Manual
2-30
Charging Discharging Action
Battery Voltage ≤ 8.9V and temp. >
20°C.
Or Battery Voltage ≤ 8.7V and temp. <
20°C.
LLC
Shut down System
R.S.O.C ≤ 5% during system is in S2R
mode.
Wakeup
System
Fast Charge Time
out: 12 Hours
Trickle Charge
Time Out: 6 Hour.
Battery BAD
&
Battery Led off
Voltage≥13.5V
OverVoltage
&
Battery Led off
In ACPI mode
• System should Save to Disk (S2D) or beeping (Low condition) depend on OS
setting.
12.9.2 Battery type
•
The KB-BIOS will support for smart battery pack by SMBus protocol.
• ACPI1.0b and PC2001 Compliant, with PC2001 spec “A mobile system must
use a Smart Battery or an ACPI control method battery”, our currently design
is ACPI control method battery.
Li-ion Battery: 11.1V/7200mAH (9 cells: 3S3P & 6 cells 3S2P)
•
Compatible with Intel’s SMBus and Philip’s I2C bus protocol.
12.9.3 Adaptor loading Protection
•
When the power consumption of system over support by AC adaptor, EC will
notify system to do throttling. The protected point is different by CPU type
and speed. Below table was detail description.
AC adaptor status Protect point Action
AC adaptor exist Voltage ≥ 1.22V
(average 2.5 minute)
Clock throttling 12.5%.
The max level is 50%
AC adaptor not
exist
12.10 EC-FW Power management support
EC will support S1 (sleep mode), S3 (standby mode) and S4 (suspend to disk)
mode to save the power consumption.
12.10.1 Power states
