JHT01 Service Manual
3-1
• Major Sub-assembly Specification
•
System interconnection (For JHT01)
1. Top View
Position Description Position Description
1 MB_PCB 25 T/P Board to MLB
2 USB/Board 26 Function Board to MLB
5 K/B to MLB (25 PIN) 27 Inverter Conn
7 EXP-CARD CONN 28 SPEAKER Conn
10 SATA HDD CONN 30 Kill_SW
20 Bluetooth Conn 32 SW
22 Power Board Conn 33 Camera Conn
23 Internal Mic Conn 34 Read Switch
24 LED
To Next Page
