JHT01 Service Manual
2-20
CMD DATA Description return
47h Speaker mute On/Off or LED control
80h Return back the control right to EC None
81h System Led on and control by OS None
82h Power management Led on and control by OS None
83h Charge Led on and control by OS None
84h Discharge LED on and control by OS None
85h Direct CD Led on and control by OS None
86h Blue Tooth Led on and control by OS None
87h One touch button Led on and control by OS None
88h All LED off and control by OS None
89h Hdd LED on and control by OS None
8Ah Fdd LED on and control by OS None
8Bh MP3 LED on and control by OS None
8Ch 2
ND
battery LED on and control by OS None
8Dh Email LED on and control by OS None
8Eh Wireless LED on and control by OS None
8Fh Numlock LED Controlled by OS None
90h Padslock (Cursorlock) LED Control by OS None
91h Capslock LED Control by OS None
92h Scrolllock LED Control by OS None
A7h Mute off None
A8h Mute on None
48h Reserved None
49h Thermal control notification
A0h FAN off and throttling disable None
A1h FAN speed level 1 on and throttling disable None
A2h FAN speed level 2 on and throttling disable None
A3h throttling enable None
A4h FAN speed level 3 on and throttling disable None
A5h FAN speed level 3 on and throttling disable None
If FAN_NUM ≥ 2
B0h FAN off None
B1h FAN on speed1 None
B2h FAN on speed2 None
B3h Throttling enable None
B4h FAN on speed3 None
B5h FAN on speed4 None
If FAN_NUM ≥ 3 None
C0h FAN off None
C1h FAN on speed1 None
C2h FAN on speed2 None
C3h Throttling enable None
4Ah Auto into S2R (Delay about 4 Secs) or S2D and
resume by timeout, This command provided
engineer to verify S2R or S2D and resume
function is OK or not
Resume count (second base), Range is from
0x02 to 0x7F
Bit7 = 0 - > Enabled S2R function
1 - > Enabled S2D function
0x02-0x7F Enabled S2R function None
