12.11.1.1 Fan control by Voltage
• EC will output voltage to control fan directly. (DTS/Tdiode Thermal Policy)
Speed stage Speed down
temperature (°C)
Speed up
temperature (°C)
Fan 1
RPM
Speed 0 0 50 0
Speed 1 45 55 2500
Speed 2 53 60 3000
Speed 3 58 65 3400
Speed 4 63 70 3800
Speed 5 68 100 4200
Speed 6
(Throttling start)
95
105 (DTS)
(Shutdown temp)
4200
