JHT01 Service Manual
2-37
Offset Description
Bit5 - Contrast button (1:pressed)
Bit6 - Brightness button (1:pressed)
Bit7 - Save to disk button (1:pressed)
9Eh
ACPI_FLAG2
Bit0 - ACPI entry S4 state
Bit1 - password enable, set 1
Bit2 - beep alarm enable, set 1
Bit3 - touch pad button (1:enable)
Bit4 - Fn state (1: fn key down)
Bit5 - CD/DVD mode selected, set 1
Bit6 - Digital mode selected, set 1
Bit7 - CD Lock mode enable, set 1
9Fh
SWI Event indicators
Bit1 - Lid open event (0=off, 1=on)
Bit2 - PME event (0=off, 1=on)
Bit3 - Power button event (0=off, 1=on)
Bit4 - Ring in event (0=off, 1=on)
Bit5 - Blue tooth wake up event (0=off, 1=on)
Bit6 - Dock in event (0=off, 1=on)
A0h
Throttling index
00: Nothing, 01: Thr 12.5%, 02: Thr 25%, 08: Thr 100%
Bit6 - (1=SW Throttling active)
Bit7 - (Throttling status; 1=HW Throttling Pin active)
A1h
DCID: Customer ID
Bit0 - DockType0, Dock on or not (0=off, 1=on)
Bit1 - DockType1, reserved
Bit4 - OS_undock OK
Bit5 - OS dock OK
Bit6 - Safe Undock OK
Bit7 - DockChange, Ultra Base had changed from docked to undock or undock to dock
(0=no, 1=yes)
A2h
OS Shutdown Temp. For system read setting. (DTS).
A3h
SYS_STATUS: System indicator
Bit0 - S1LED, S1 state LED (0=LED off, 1=LED on)
Bit1 - S3LED, S3 state LED (0=LED off, 1=LED on)
Bit2 - VGAQ, VGA H/W suspend (0=VGA on, 1=VGA suspend)
Bit3 - PCMQ, PCMCIA H/W suspend (0/1=PCMCIA on/suspend)
Bit4 - PCMR, PCMCIA H/W reset (0=disable, 1=enable)
Bit5 - ADP, Ac adapter (0=offline, 1=online)
Bit6 - SYSR6 (reserved)
Bit7 - SYSR7 (reserved)
A4h
WAKEUP_ENABLE: Enable wake up function
Bit0 - PMEWAKE (PME Wk Enable:0=Disable, 1=Enable)
Bit1 - MDMWAKE (Modem Wk Enable:0=Disable, 1=Enable)
Bit2 - LANWAKE (LAN wakeup enable:0=Disable, 1=Enable)
Bit3 - RTCWAKE (RTC wakeup Enable: 0=DIsable, 1=Enable)
Bit4 - WLANWAKE (Wireless LAN wakeup Enable:0=Disable, 1=Enable)
Bit5 - RESERVED
Bit6 - KEYWAKE (Keyboard wakeup enable:0=Disable, 1=Enable)
Bit7 - MOUSWAKE (Mouse wakeup enable:0=Disable, 1=Enable)
