JHT01 Service Manual
2-42
Offset Description
2Ch-2Dh
Full charge capacity
2Eh
Gasgauge
2Fh
Battery cycle counter
30h-31h
Battery current
32h-33h
Battery average current
34h
System power consumption
35h
Battery Volt
36h
Battery Temp
37h
Battery Average Temp
38h-39h
Battery charge current
3Ah
Battery current Temp sample counter
3Bh
Battery Command index for read battery through SMBus
3Ch
Count up to communicate battery
3Dh
Count up if battery is arrived overtemp
3Eh-3Fh
SMBus status
40h
Battery over voltage counter
41h
Communication fail counter
42h
Battery voltage of ADC
43h-44h
Cell1 voltage
45h-46h
Cell2 voltage
47h-48h
Cell3 voltage
49h-4Ah
Cell4 voltage
50h
Battery staus1
Bit0 - Battery exist
Bit1 - Battery full
Bit2 - Battery empty
Bit3 - Battery first in
Bit4-5 - reserved
Bit6 - Battery read complete
Bit7 - Use LI_ION or NI_MH#
51h
Battery staus2
Bit0 - Low battery
Bit1 - Check EDV1
Bit2 - Set EDV1
Bit3 - Battery shutdown 5%
Bit4 - Start to read battery
Bit5 - Start to count communication counter
