Total regulation 5V±5% depend on VCC static and
Transient Tolerance--
Ripple voltage 100mVp-p max 20mVp-p max@36A
Item +0.9VSP +3VALWP +1.05VSP
nominal voltage +0.9V +3.3V +1.05V
Min. current 0A 0A 0A
Max. current 1.4A 5.5A 8.16A
Peak current 2A 7.85A 11.66A
Total regulation 0.9V±5% 3.3V±5% 1.05V±5%
Ripple voltage 40mVp-p max 100mVp-p max 60mVp-p max.
Item +1.8VP +1.5VSP
nominal voltage +1.8V +1.8V
Min. current 0A 0A
Max. current 6.1A 2.89A
Peak current 8.7A 4.13A
Total regulation 1.8V±5% 1.5V±5%
Ripple voltage 100mVp-p max 100mVp-p max
• VOLTAGE IDENTIFICATION CODES
VID6 VID5 VID4 VID3 VID2 VID1 VID0 VDAC
0 0 0 0 0 0 0 1.5000
0 0 0 0 0 0 1 1.4875
0 0 0 0 0 1 0 1.4750
0 0 0 0 0 1 1 1.4625
0 0 0 0 1 0 0 1.4500
0 0 0 0 1 0 1 1.4375
0 0 0 0 1 1 0 1.4250
0 0 0 0 1 1 1 1.4125
0 0 0 1 0 0 0 1.4000
0 0 0 1 0 0 1 1.3875
0 0 0 1 0 1 0 1.3750
0 0 0 1 0 1 1 1.3625
0 0 0 1 1 0 0 1.3500
