Compaq Deskpro 2000 Service & Reference Guide

Compaq Service Reference Guide A-5
External Infrared Transceiver
Connector and Icon Pin Signal
86
53
2
1
4
7
1
2
3
4
5
6
7
8
Transmit
Receive
Ground
5V
Mode
Not Used
Not Used
Not used
Monitor
Connector Pin Signal
54321
109876
15 14 13 12 11
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Red Analog
Green Analog
Blue Analog
Monitor ID
Ground
Ground
Ground
Ground
+5V DC
Ground
Monitor ID
DDC Serial Data
Horizontal Sync
Vertical Sync
DDC Serial Clock
