Compro IP55 / 60 / 70 Network Camera
For the IP70 camera.
6 12 13 14
10
5 114
21 3 7 98
Figure 2-4. Front and rear view of IP70
Light sensor.
Lens
IR Lamp x 6 (inside)
Microphone
Speaker
LED status indicator
USB Wireless adaptor connector
Audio Output
Reset Button
microSD card slot (on the side)
Microphone Input
Power connector
Microphone Input
Power connector
Camera Layout
