25. TROUBLESHOOTING
(1) The time recorder does not work and LCD shows no display.
1) Ensure the power code is properly plugged into the AC outlet.
2) Check for blown fuse on the main PC board (F1).
(2) The time recorder has become abnormal
Press the Reset switch.
*Please refer to page 34.
(3) Printing on the time card is not in accordance to the L.C.D. display time.
Check card detection card sensor.
(4) Memory is not being kept after power failure.
Check if the lithium battery (BAT1 on main PC board) is faulty.
(5) The printing position is incorrect.
Setting of pay ending date is not correct. Please set them correctly.
(6) Light printing.
a. The ribbon is worn out, please replace the ribbon cassette.
b. The ribbon cassette is not installed correctly, please reinstall it.
(7) List of error codes:
a. E-01: The remaining life of lithium battery for memory back-up is short.
b. E-30: Vertical motor can not run or Vertical motor counter sensoris not
normal.
c. E-31: Horizontal motor can not run or Horizontal motor counter sensor is not
normal.
d. E-32: The time card is jammed.
e. E-33: The sensor unit (Bottom sensor) is not normal.
f. E-37: The front or back of the time card is inserted incorrectly.
g. E-38: Check the print head “home position” sensor.
h. E39: The time card is damaged.
i. E-40: Input incorrect data.
j. E-41: The start day and end day of daylight saving time is the same date.
k. E-49: The card transfer error, maybe the new card number is in used.
l. E-50: Input incorrect data (for technicians only)
m. E-51: The time card was inserted within one minute after the last punch.
n. E-53: Over 50 time cards are used.
o. End: The time card is fully printed before pay ending day, must use card
transfer function to make a new card to replace the old card.
54
