Contents XPS/XPS-E User's Manual

4  COMSOFT

2.1.2 XPS-E Top Hat Rail Model

Serial

Interface

PROFIBUS

Interface

Address Switch

RUN-LED

BUS-FAIL-LED

MODE-LED

TX-LED

RX-LED

Power Supply

Connector

Figure 3: Connectors and Interfaces of XPS-E
