XPS/XPS-E User's Manual Contents
COMSOFT 3
2.1 Connection of the Gateway
2.1.1 XPS Desk Model
Status LED
RS232-
Interface
Terminator ON/OFF
PROFIBUS-DP
Interface
Address
Switch
Front Side
Rear Side
Power Supply
Figure 2: Connectors and Interfaces of XPS
