2.4.3 Parameter Description
The parameters marked with (*) are the default values. These are used if
inadmissible parameters are entered during parameterisation.
2.4.3.1 Baud Rate
Baud Rate (bit/s) Value (dec) Value (hex)
150 1 0x01
300 3 0x03
600 6 0x06
1.200 12 0x0C
2.400 24 0x18
4.800 48 0x30
9.600 * 96 0x60
19.200 192 0xC0
Table 3: Baud Rate of Serial Interface Octet 12
2.4.3.2 Character Transmission Mode
Transmission Mode Value (dec) Value (hex)
8 Data bits, No Parity, 1 Stopbit (8N1) * 56 0x38
7 Data bits, No Parity, 2 Stopbits (7N2) 78 0x4E
7 Data bits, Even Parity, 1 Stopbit (7E1) 69 0x45
7 Data bits, Odd Parity, 1 Stopbit (7O1) 79 0x4F
Table 4: Character Transmission Modes Octet 13
The operating mode: 7 data bits, No Parity, 1 StopBit is not supported.
Note
