2.4 set_prm Parameterisation
The Bytes 1-7 are PROFIBUS-DP standard parameters, Byte 8-23 are device-
specific parameters (
usr_prm).
Octet Parameter Name Value
1
Station_status
0x80*
2
WD_fact_1
0x00
3
WD_fact_2
0x00
4
Min T
SDR
55
5
Ident_Number [0]
0x95
6
Ident_Number [1]
0x10
7
Group_Ident
0x00
8..11 Reserved ---
12 Baud Rate setting of serial interface See Table 3
13 Character Transmission Mode of serial interface See Table 4
14 Handshake setting of serial interface See Table 5
15 XOFF-Timeout of serial interface See 2.4.3.4
16 Receive Mode of PROFIBUS interface See Table 6
18 Trigger character for serial triggered mode
(usually LF (0x0A))
See Table 8
19..23 Reserved ---
Table 1: set_prm
(
*
)
Freeze_Req and Sync-Req are not supported.
