PANEL INSIDE TEMP
ACT 100°F
Function
DRYER SETUP
PROC ALM DISP OTHER
SETUP PROCESS
PROC REGEN OTHER
SETUP PROCESS
PROC PROPID RETPID
PROCESS TEMPERATURE
RANGE 70°F - 450°F
This screen shows the temperature inside
the control enclosure. It is measured at the
lower right corner of the control board.
This is the Dryer Setup screen. It can be
found by pressing the Select Category but-
ton under the word Setup on the Main
Menu (screen 12). By pressing the Select
Category buttons under the titles, the user
can select to see setup information for
Process, Alarms, Display, or Other.
This is the Setup Process screen. It can be
found by pressing the Select Category but-
ton under the word Proc on the Dryer
Setup (screen 36). By pressing the Select
Category buttons under the titles, the user
can select to see setup information for
Process, Regeneration, or Other.
This is the second Setup Process screen.
It can be found by pressing the Select
Category button under the word "Proc" on
the Setup Process screen (37). By press-
ing the Select Category buttons under the
titles, the user can select to see setup infor-
mation for Process, Process PID, or Return
Air PID if the optional aftercooler flow
control is installed. Note: When config-
ured as a central dryer, you will not see the
process PROPID.
This screen shows the allowable tempera-
ture range for setpoint temperatures. With
the proper password (see page 4-32,
screen 85), this range can be narrowed.
4-20 l Operation
Control Function Descriptions(continued)
NOTE: Conair does not
recommend low setpoints
under 150
°F {66°C} due
to nuisance alarms.
✐
NOTE: Software may allow
the Process temperature
setpoint limit up to 450
°F
{232
°C}, however Conair
does not recommend a set-
point limit over 375
°F
{191
°C} due to nuisance
alarms.
✐
NOTE: Conair is not responsi-
ble for damage caused by
excessively high drying
setpoints that are not in
accordance with your drying
material recommendations.
✐
To Next Page
