Typical Applications (continued)
Model Drying Temperature Range
Low temperature (with precooler)* 100° - 150°F {38° - 66°C}
Standard 150° - 240°F {66° - 116°C}
High heat (with aftercooler)* 150° - 375°F {66° - 191°C}
Low-high (with aftercooler & precooler)* 100° - 375°F {38° - 191°C}
* See page 3-13, Appendix B
• Throughput rates of 150 to 400 lbs {68 to 149 kg} per hour
(some materials can be run at a higher rate).
• Dewpoints of -40°F {-40°C}.
Use the aftercooler when:
• You are drying at temperatures over 240°F {116°C}.
• Throughput rates are less than 50% of the dryer’s rated capacity.
• You are pre-drying material at temperatures over 150°F {66°C}.
Dryer Options
• Dewpoint monitor / dewpoint control
• Audible and visual alarm
• Temperature setback
MDC Options (Models 150 & 200 only)
• Non dry air conveying
• Machine loading only
• Self-loading (machine and hopper loading)
Description l 2-3
2
Description
When supplied for central drying
applications, the W series dryer
is not equipped with a process
heater. Therefore, as a central
dryer, the W dryer will only sup-
ply dry air to the hoppers.
