Conair 200 - Page 50

4-14 l Operation
Screen
Screen 28-43 require access
code 755.
SCREEN 34 (Test Mode Screen)
SCREEN 35 (Test Mode Screen)
SCREEN 36 (Test Mode Screen)
SCREEN 37 (Test Mode Screen)
SCREEN 38 (Test Mode Screen)
Function
Control Function Descriptions
(continued)
This is the Test Mode screen for the isola-
tion contactor. By pressing the (+) or (-)
keys, the setting can be changed. When
set to "On", the isolation contactor output
will be turned on for 3 seconds and then
shut off automatically.
This is the Test Mode screen for the alarm
output (horn and/or red light). By pressing
the (+) or (-) keys, the setting can be
changed. When set to "On", the alarm out-
put will be turned on for 3 seconds and
then shut off automatically.
NOTE: The alarm light on the membrane
switch will not come on. If the optional
alarm horn or red light is not installed
nothing will happen.
This is the Test Mode screen for the pre-
cooler flow control valve. By pressing the
(+) or (-) keys the setting can be changed.
When set to "On" the precooler flow con-
trol valve output will be turned on for 3
seconds and then shut off automatically.
NOTE: If the optional precooler flow control
valve is not installed nothing will happen.
This is the Test Mode screen for the after-
cooler flow control valve. By pressing the
(+) or (-) keys, the setting can be changed.
When set to "On", the aftercooler flow
control valve output will be turned on for
3 seconds and then shut off automatically.
NOTE: If the optional aftercooler flow con-
trol valve is not installed nothing will hap-
pen.
This screen is not used in the current
program.
