2.4.2 DATA TRANSMISSION FROM RDC TO TXRX (OR
INTERFACES)
2.4.2.1 OPERATIONAL CONTROL SENTENCE 2
$PCO2,x,a,aa,aaa,a,a,a,a,hh,a*hh<CR><LF>
│ │ │ │ │ │ │ │ │ └─ MGN Heater: W = warm, C = cold else NULL (AUTO)
│ │ │ │ │ │ │ │ └─ Tuning adjust (min 00H, max FFH). If Automatic don't care.
│ │ │ │ │ │ │ └─ M = Manual Tuning, A = Automatic Tuning
│ │ │ │ │ │ └─ V = Video test else NULL (OFF)
│ │ │ │ │ └─ P = Performance Monitor ON else NULL (OFF)
│ │ │ │ └─ J = Jitter ON else NULL (OFF)
│ │ │ └─ Rxx = Antenna Rotating ON with xx RPM ( 01 ÷ 60) else NULL (OFF)
│ │ └─ Transceiver control (³)
│ └─ M = Request Master of Transceiver, S = Slave (²)
└─ Selected Transceiver Number (¹)
Notes:
(¹) Transceiver Number: 1, 2, 3, 4 (SPARE in stand alone TXRX)
(²) Master/Slave request (SPARE in stand alone TXRX and single equipments)
(³) Transceiver control:
Field type Field Descriptions
SB
Stand By
SH
Short pulse, High frequency
SM
Short pulse, Medium frequency
SL
Short pulse, Low frequency
MM
Medium pulse, Medium frequency
ML
Medium pulse, Low frequency
LL
Long pulse, Low frequency
2.4.2.2 SECTOR BLANKING SENTENCE
$PSE2,a,xxx.x,xxx.x,xxx.x,xxx.x*hh<CR><LF>
│ │ │ │ │
│ │ │ │ └─ End Sector 2
│ │ │ └─ Start Sector 2
│ │ └─ End Sector 1 (¹)
│ └─ Start Sector 1
└─ D = Sector Blanking Values, R = Sector Blanking Request (
2
)
Notes:
(¹) Start & End Sector units are degree. Es: 90.6.
This value will be rounded depending from the position sensor used
(
2
) If Sector Blanking Request, don't care
