SRT X-BAND RADAR SYSTEMS
OPERATION
304202P003 2.8 Rev. C
│ │ │ │ │ │ │
│ │ │ │ │ │ └─ Pot ID #6, PM Noise diode current
│ │ │ │ │ └─ Pot ID #5, Tuning Offset
│ │ │ │ └─ Pot ID #4, Video Level
│ │ │ └─ Pot ID #3, Performance Monitor Amplitude
│ │ └─ Pot ID #2, Performance Monitor Opening
│ └─ Pot ID #1, STC Slope
└─ Pot ID #0, STC Amplitude
Notes:
Potentiometer decimal Value : Range 0 ÷ 99.
2.4.3.5 SECTOR BLANKING SENTENCE
$PSE2,,x.x,x.x,x.x,x.x*hh<CR><LF>
│ │ │ │
│ │ │ └─ End Sector 2
│ │ └─ Start Sector 2
│ └─ End Sector 1 (¹)
└─ Start Sector 1
Notes:
(¹) Start & End Sector units are degree. Es: 90.6.
2.4.3.6 WRONG COMMAND RETURN (NACK)
$PNAC,x,aaa,xx,xx*hh<CR><LF>
│ │ │ │
│ │ │ └─ Wrong field (³)
│ │ └─ Error Code (²)
│ └─ Refused Sentence (if recognized) (¹)
└─ Transceiver Number (as sentence STS or NULL in stand alone TX/RX )
Notes:
(¹) See list of accepted sentences
(²) Numeric value, from 0 to 99, command dependent (see list below)
(³) Field number. Incremental from 1 after sentence code.
Es. 1:
$PNAC,2,COP,01,05*hh<CR><LF>
Meaning: feedback on error inside COP command for transceiver 2 through TXRX Interface,
error type #01, field #05 (wrong JITTER field)
Es. 2:
$PNAC,,COP,01,37*hh<CR><LF>
Meaning: same feedback error directly from TXRX
-
2.4.3.7 HEALTH SENTENCE 2
