SRT X-BAND RADAR SYSTEMS
INSTALLATION
304202P003 8.10 Rev. C
8.3.4 Pre Setup Procedures
This paragraph provides information concerning the preliminary controls and
procedures to be done as a completion of the electrical installation and before
supplying the unit with power and before performing the System Setup
Procedure:
NOTE
Powering the Radar System is not included in the Pre Setup
Procedure
− Carry out a careful visual inspection of the installed
components referring to the layouts of the unit and to the
interconnection drawings
− Carefully check the integrity of the fuses
NOTE
Powering the Radar System is not included in the Pre Setup
Procedure
8.3.4.1 Ship power Voltage
− The unit must is connected to ship main voltage trough the Radar display
console DC-CORE or trough the SRT adapter box.
− Cable section shall be ≥ 4mm to support a 15A current.
