SRT X-BAND RADAR SYSTEMS
PREVENTIVE MAINTENANCE
304202P003 4.2 Rev. C
− SAFETY PRECAUTIONS: it indicates the precaution to be followed in
order to ensure a safe Preventive Maintenance operation execution
Table 4.2.2 - List of the Preventive Maintenance Cards, for each of them,
indicates the periodicity and the required time.
Table 4.2.1 - List of Recommended Tools and Instruments
Pr. Description Type Note
1 Set of screwdrivers USAG Insulated handle
2 Set of open wrenches USAG
3 Set of socket wrenches USAG
4 Set of socket hexagonal USAG
5 Set of communication tools -
6 30 W welders -
7 Electric Solder Iron
8 Desoldering tool SILVERSTAT
9 Vacuum cleaner
10 Digital multimeter CHAUVIN ARNOUX
CPA 9651 (3:5)
or equivalent
11 Oscilloscope Tektronix
Table 4.2.2 - List of the Preventive Maintenance Cards
Card Operation Periodicity
Required
Time
1 Check of the External Preservation Status S1 15'
2 Internal Inspection and General Cleaning S2 15'
3 Replacement of the Magnetron WR1-8000 h 30'
