SRT X-BAND RADAR SYSTEMS
OPERATION
304202P003 2.5 Rev. C
2.4.2.3 TIMERS INITIALIZATION
$PTIM,x,x,x,x.x,x.x,x.x,x.x,x.x,x.x,x.x*hh<CR><LF>
│ │ │ │ │ │ │ │ │ │
│ │ │ │ │ │ │ │ │ └─ Timer M-Pulse Low Freq.
│ │ │ │ │ │ │ │ └─ Timer S-Pulse Low Freq.
│ │ │ │ │ │ │ └─ Timer S-Pulse Medium Freq.
│ │ │ │ │ │ └─ Timer L-Pulse Low Freq. (²)
│ │ │ │ │ └─ Timer M-Pulse Medium Freq.
│ │ │ │ └─ Timer S-Pulse High Freq.
│ │ │ └─ Timer Standby
│ │ └─ Status 3
│ └─── Status 2
└───── Status 1 (¹)
Notes:
(¹) Command 1: 1 = Request for transmission of actual values
2 = Initialization of values .
3 = Reset of values.
Command 2: Spare
Command 3: Spare
(²) Timers : Integer value to pre-set the operated time. LSB is equal to 1 hour.
If Command 1 = 1 or Command 1 = 3 don't care.
2.4.2.4 DIGITAL POTENTIOMETERS
$PDPC,a,x,x*hh<CR><LF>
│ │ │
│ │ └─ Potentiometer increment signed value (³)
│ └─ Potentiometer ID (²)
└─ R = potentiometer value Request, F = potentiometer Factory preset else
NULL(¹) A = auto adjust (°)
Notes:
(¹) Factory preset is available for latest TX/RX versions.
(²) Pot. ID
#Potentiometer to be upgraded:
0 PRE-STC AMPLITUDE
1 PRE-STC SLOPE
2 P.M. OPEN
3 P.M. DISTANCE (Power Level)
4 TUNING INTICATION
5 TUNE OFFSET
