SRT X-BAND RADAR SYSTEMS
INSTALLATION
304202P003 8.11 Rev. C
8.3.4.2 Compass Safe Distance
Every unit should be located outside the minimum magnetic compass safe
distance according to the following table:
Unit Unit type
Safe distance to
the standard
magnetic com-
pass
(m)
Safe distance to
the steering
magnetic com-
pass
(m)
Reduced Safe
distance to the
standard mag-
netic compass
(m)
Reduced Safe
distance to the
steering mag-
netic compass
(m)
12.5 or 25 kW
X-Band SRT
Transceiver
SRTX/12-002
SRT/12-003
or
SRTX/25-002
SRT/25-003
1.35 0.85 0.85 0.55
SRT Adapter
Box
SRTAB-001
1.20 0.50 0.75 0.30
